ABB AUX T7-T7M-X1 2Q 400Va.c.
General Information
| Extended Product Type: | AUX T7-T7M-X1 2Q 400Va.c. |
| Product ID: | 1SDA062102R1 |
| EAN: | 8015644646424 |
| Catalog Description: | AUX T7-T7M-X1 2Q 400Va.c. |
| Long Description: | 2 CHANGEOVER CONTACTS OPEN-CLOSED 400V AC T7-T7M-X1 |
Description
| Environmental | |
| Environmental Information: | 9AKK108467A6707 |
| Material Compliance | |
| REACH Declaration: | 9AKK108466A1425 |
| RoHS Information: | 9AKK108466A1424 |
| RoHS Status: | Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019 |
| Conflict Minerals Reporting Template (CMRT): | 9AKK108467A5658 |
| Toxic Substances Control Act – TSCA: | 9AKK108467A8326 |
| Ordering | |
| Order Code US and Canada: | KT7XAS2 |
| EAN: | 8015644646424 |
| Minimum Order Quantity: | 1 piece |
| Customs Tariff Number: | 85389099 |
| Dimensions | |
| Product Net Weight: | 0.04 kg |
| Container Information | |
| Package Level 1 Units: | 1 piece |
| Package Level 1 Width: | 145 mm |
| Package Level 1 Height: | 40 mm |
| Package Level 1 Depth / Length: | 250 mm |
| Package Level 1 Gross Weight: | 0.07 kg |
| Package Level 1 EAN: | 8015644646424 |
| Additional Information | |
| Product Main Type: | Accessories for Tmax T |
| Product Name: | Accessory |
| Product Type: | Accessory |
| Suitable For: | T7, X1 |
| Suitable for Product Class: | SACE Emax SACE Tmax T |
| Technical | |
| Configuration Type: | Loose or configurable |
| Gross Volume: | 1,450 cm³ |
| Number of Auxiliary Contacts CO (SPDT): | 2 |
| Standards: | IEC |
| Certificates and Declarations | |
| Data Sheet, Technical Information: | 1SDC210015D0208 1SDC210300D0201 |
| Declaration of Conformity – CE: | Refer to the EU Declaration of the relative Circuit Breaker |
| Instructions and Manuals: | 1SDH000529R0604 |
| Classifications | |
| ETIM 8: | EC000041 – Auxiliary contact block |
| ETIM 9: | EC000041 – Auxiliary contact block |
| IDEA Granular Category Code (IGCC): | 4743 >> Auxiliary contact block |
| Object Classification Code: | Q |
| UNSPSC: | 39121522 |
| WEEE Category: | 5. Small Equipment (No External Dimension More Than 50 cm) |
| eClass: | V11.1 : 27371302 |
