| Material Compliance |
| Conflict Minerals Reporting Template (CMRT): |
9AKK108467A5658 |
| REACH Declaration: |
1SCC011021D0201 |
| RoHS Information: |
1SCC011020D0201 |
| RoHS Status: |
Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019 |
| Ordering |
| Minimum Order Quantity: |
10 piece |
| Customs Tariff Number: |
85389099 |
| Country of Origin: |
Bulgaria (BG) |
| Popular Downloads |
| Data Sheet, Technical Information: |
1SCC301020C0201 |
| Instructions and Manuals: |
1SCC390026M0018 |
| Mechanical Drawings: |
OA1G10.stp |
| Dimensions |
| Product Net Width: |
11 mm |
| Product Net Height: |
37 mm |
| Product Net Depth / Length: |
21 mm |
| Product Net Weight: |
0.015 kg |
| Technical |
| Conventional Free-air Thermal Current (Ith): |
16 A |
| Conventional Thermal Current (Ithe): |
Fully Enclosed 16 A |
| Rated Insulation Voltage (Ui): |
690 V |
| Number of Auxiliary Contacts NO: |
1 |
| Rated Voltage (Ur): |
690 V |
| Certificates and Declarations |
| Declaration of Conformity – CE: |
1SCC390020D2704 |
| Container Information |
| Package Level 1 Units: |
bag 10 piece |
| Package Level 1 Width: |
11 mm |
| Package Level 1 Depth / Length: |
40 mm |
| Package Level 1 Height: |
30 mm |
| Package Level 1 Gross Weight: |
0.02 kg |
| Package Level 1 EAN: |
6417019102443 |
| Classifications |
| Object Classification Code: |
N/A |
| ETIM 8: |
EC000041 – Auxiliary contact block |
| ETIM 9: |
EC000041 – Auxiliary contact block |
| UNSPSC: |
39121522 |
| IDEA Granular Category Code (IGCC): |
4743 >> Auxiliary contact block |
| eClass: |
V11.1 : 27371302 |
| WEEE Category: |
Product Not in WEEE Scope |
| E-Number (Finland): |
3601912 |
| E-Number (Sweden): |
3171480 |
