| Technical |
| Number of Rows: |
3 |
| Configuration Type: |
Assembled with DIN-rail |
| Cover Plate Type: |
Door |
| Mounting Type: |
Surface mounting |
| Door Type: |
Single |
| Door Surface Finishing: |
Opaque |
| Housing Material: |
Plastic |
| Cover Style: |
with Notch |
| DIN Place Units: |
36 |
| RAL Number: |
RAL 9016 – Traffic White |
| Color: |
White |
| Terminal Type: |
Screw Terminals |
| Material Compliance |
| RoHS Information: |
9AKK108468A2421 |
| RoHS Status: |
Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019 |
| RoHS Date: |
20221015 |
| REACH Declaration: |
9AKK108469A7731 |
| REACH Information: |
False – does not contain substances > 0.1 mass percentage |
| REACH Date: |
20240429 |
| Conflict Minerals Reporting Template (CMRT): |
9AKK108468A3363 |
| Environmental |
| Degree of Protection: |
IP41 |
| Protection Class: |
Isolated (Class II) |
| Dimensions |
| Width in Number of Modular Spacings: |
36 |
| Product Net Width: |
297.000 mm |
| Product Net Height: |
119.000 mm |
| Product Net Depth / Length: |
512.000 mm |
| Product Net Weight: |
2.410 kg |
| Ordering |
| Package Level 1 Units: |
box 1 piece |
| Package Level 1 Gross Weight: |
2.410 kg |
| Certificates and Declarations |
| Declaration of Conformity – CE: |
9AKK108468A2421 |
| Installation |
| Instructions and Manuals: |
9AKK108468A8241 |
| Popular Downloads |
| Classifications |
| ETIM 8: |
EC000214 – Small distribution board |
| ETIM 9: |
EC000214 – Small distribution board |
| WEEE Category: |
4. Large Equipment (Any External Dimension More Than 50 cm) |
| WEEE B2C / B2B: |
Business To Consumer |
| CN8: |
85371099 |
| eClass: |
V11.0 : 27142409 |
